DVBMonitor

DVB Networks are getting more complex rapidly. Besides the growing amount of Services, also the varieties of components that must connect and interact in a specific way to be successful are getting beyond human perception.

All activities together are responsible for the behavior and quality of a DVB network. Thereby DVB networks evolve constantly with changes in services, parameters, devices and their firmware releases. It can be concluded that a DVB network owner constantly needs to be aware of the quality of his DVB network! The most reliable means to know how a DVB network performs is to continuously measure in real-time its behavior through comparison to a set of recommendations for various stream elements.

The key question which has to be answered is: What do you accept or not in your DVB network?
To ensure that all DVB signals meet the customer requirements, constant real-time compliancy checks are needed.

Features

  • Web based Application
  • Multiple Transport Streams
  • Multiple Configurable Compliancy Checks
  • Multiple Templates
  • Multiple Notifications
  • Multiple Organizations
  • Multiple Sites
  • Multiple Users
  • Freeze detection
  • Black detection
  • Silence detection
  • Input Lost detection
  • PID Lost detection
  • Service Lost detection
  • Multiple walls
  • Acknowledge mode
  • Visual signalling
  • Audio alerts
  • SNMP traps
  • Mail alerts
  • DVBMonitor connectivity
  • MPEG-2 / AVC (H.264) / HEVC (H.265) video
  • MPEG / AAC, Dolby® Digital+, Dolby® E, Dolby® AC-4 audio
  • Web enabled
  • Remote control
  • Teletext
  • DVB-subtitles
  • Clocks
  • Images
  • Preferences
  • Aspect ratio detection
  • ETR-290 (Level 1, Level 2, Level 3, and 4*) measurements
  • SCTE-35 monitoring/logging
  • PID structures
  • Service structures
  • SI/PSI/PSIP structures
  • ETR-290 compliance
  • Timing
  • Descriptors
  • Bitrate measurement
  • Teletext
  • Subtitling
  • Thumb overview
  • Video Quality
  • GOP structures
  • PTS-DTS Timing
  • Table overview
  • Table Change monitor
  • Descriptor overview
  • Hex Viewer
  • PCR Timing
  • Logging
  • Filtering
  • EPG
  • Audio measurement
  • Loudness measurement
  • And many more!!

Input Support

File, HD/SD SDI, ASI, DVB-C, DVB-T/T2, DVB-S/S2, DVB-H, Unicast, Multicast, SRT and
Live OTT Streaming (RTSP/RTMP/RTP/HLS/Smooth Streaming/MPEG_DASH).


Type Description
Software Base
DM-Base DVBMonitor base software license, including 10 License Points
Software Options
DM+10 10 extra License Points
DM+40 40 extra License Points
DM+100 100 extra License Points
DM+DD5 5 Dolby ® Digital Plus decoders
DM+DD20 20 Dolby ® Digital Plus decoders
DM+DD50 50 Dolby ® Digital Plus decoders
DM+DE5 5 Dolby ® -E decoders



License Point System

Input points are always needed, before Video/Audio/Data points can be used

Inputs:
1 SPTS = 1 License Point
1 MPTS = 5 License Points
1 TS, without monitoring = 0,5 License Point

Video:
1 SD TV component = 1 License Point
1 HD TV component = 2 License Points
1 UHD TV component = 4 License Points
1 LD TV component = 0,5 License Point

Audio:
1 Audio = 0,5 License Point
For Dolby decoding, also extra Dolby licenses are needed

Data:
1 HbbTV = 1 License Point
1 Teletext = 1 License Point
1 DVB-Subtitle = 1 License Point
1 SCTE-35 = 1 License Point

Latest version
Description Version Download Size
Manual August 2022 9 MB
Application 64bit (dongle required) 26 June 2024
V1.1.30.169
51 MB
Remote Live Viewer (32bit) 18 December 2013 5 MB
General
Description Download Size
DVBMonitor Flyer 3 MB
DVBControl Brochure 12 MB
General Terms and Conditions 250 kB
